Portable Power Box Bates 50Amp 6-15 (PPB)
The PPB 6-15 Bates Model is specifically designed for the unique power needs of the US TV, film, and entertainment industries.
The PPB 6-15 Bates Model is 50 Amps
Know the Product
Portable Power Box Bates 50Amp 6-15 (PPB)
PPB 6-15 Bates Model: Purpose-Built Power for the Entertainment Industry
The PPB 6-15 Bates Model is specifically designed for the unique power needs of the US TV, film, and entertainment industries. Equipped with a powerful 6.5 kW inverter and a 15-kWh battery capacity, this model provides reliable, emissions-free power tailored to entertainment applications. Featuring the industry-standard Bates connector, the PPB 6-15 Bates Model offers 120V output and both a 50A stage-pin (Bates) style outlet and inlet, ensuring seamless compatibility with entertainment lighting equipment. With fast charging in just 2.5 hours, this unit is the ideal portable power solution for production sets, film shoots, and live events, delivering the performance and convenience required by industry professionals.
PRODUCT CODE: PPB-6-15-US-B
Features and Benefits
Challenges on the Job
- Portable high-capacity power storage device
- 50A stage-pin (Bates) style outlet and inlet
• Chargeable with 120V mains and solar photovoltaic (PV)
• 2x GFCI 20A, 1x 30A (L5-30R) and 1x stage-pin (bates style) 50A outlet, also 1x USB-A and USB-C
• Use across variety of industries and applications
• Up to 15kwh of battery capacity
• Safe for indoor and confined spaces use
• No Noise or emissions
• No fuel needed
• Touch safe solar pv connector
• RCD protection for user and device
• Battery management display
• Thermal overload protection
• the unit is complete with circuit breaker protection
• Easy overnight re-charge of battery storage
• 6.5kW output power
• Easily manoeuvrable with durable frame
• Plug and Play
• No Noise
• No emissions
• Multiple application where noise & emissions is not acceptable or permissible
Specifications
Specification | PPB 6-15 Bates |
Power Output | 6.5kW |
Battery size | 15kWh |
Outlets | 2x Dual 20A 120V GFCI, 1x L5-30R 30A 120V, 1x stage pin 60A 120V (50A Max), USB-A/USB-C, 5V 3.0A |
Inlet | 1x 5-15P 15A 120V, 1x stage pin 60A 120V (50A Max), 8kW solar |
Charging time | 100% 120V – 9hrs 100% 240V – 3hrs |
Peak surge | 13kW 5 seconds |
Dimensions | 38.4 L x 20.3 W x 36.7 H in |
Weight | 474lbs |
Safety Compliance
Safety compliance:
Battery Certifications: UL 1973, UN38.3, CE
Inverter:
CNAS IEC 62109-1:2010 and 62109-2:2011 compliant
CE-EMC tested and compliant according to
EN 61000-6-3:2007+A1:2011+AC:2012
EN 61000-3-12:2011
EN 61000-3-11:2000
EN 61000-6-2:2005+AC:2005
